Condition : New
Steering : Left
Horsepower : 351 - 450hp
Emission Standard : Euro 3
Brand Name : sinotruk
Place of Origin : Hubei, China
Segement : Heavy truck
Market Segement : Engineering transportation
Engine Brand : WEICHAI
Fuel Type : Diesel
Engine Capacity : > 8L
Cylinders : 6
Gear Box Brand : FAST
Transmission Type : Manual
Forward Shift Number : 10
Reverse Shift Number : 2
Maximum Torque(Nm) : 1500-2000Nm
Dimensions (L x W x H) (mm) : 8500X2500X3550
Cargo Tank Dimension : 5800x2300x1500
Cargo Tank length : 5.3-6.2M
Gross Vehicle Weight : 20-25T
Capacity (Load) : 21 - 30T
Fuel Tank Capacity : 300-400L
Drive Wheel : 6x4
Passengers : 3
Driver's Seat : Normal
Rear Camera : None
Cruise Control : None
ABS(Antilock Braking System) : None
ESC(Electronic Stability Control System) : None
Touch Screen : None
Multimedia System : None
Window : Automatic
Air Conditioner : Automatic
Tire Number : 11
After-sales Service Provided : Online support, Video technical support
Price : CN¥144,614.00/units 1-4 units
hongyan dumper truck hongyan kingkan dumper truck hongyan tipper truck hongyan heavy dump truck hongyan heavy-duty dump truck hongyan dump truck 6x4
Products Technical Specification | ||
Brand-Series | HONGYAN | |
Chassis Model | CQ3254HTG384 | |
Emission Standard | Euro3 | |
Fuel type | Diesel | |
Cabin | Genlyon short cab with A/C (optional:Genlyon Flat Top Cab) | |
Country of origine | China | |
Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 8275*2500*3550 |
Wheel base | 3800+1400 | |
Front overhang | 1435 | |
Rear overhang | 1675 | |
Front /rear tread(mm) | 2006/1850 | |
Weight data (kg) | Gross weight (kg) | 25000 |
Loading weight (kg) | 12780 | |
Curb weight(kg) | 12090 | |
Cargo body Description | Crago body dimensions (mm) | 5400*2300*1300 |
Crago body thickness | side 6mm thickness;bottom 8mm thickness | |
Lifting System | Middle hoisting | |
Whole vehicle main performance | Max. speed (km/h) | 80 |
Max. grade ability (%) | 35 | |
Approach/Departure(°) | 23/15 | |
Leaf Spring NO. | 9/12 | |
Engine | Model | WP10.340E32 |
Maximum power | 250kw /340hp | |
4 stroke direct injection diesel engine | ||
6 cylinder in-line with water-cooling, turbo-charging and inter-cooling | ||
Displacement (L) | 9.726 | |
Engine Manufacturer | weichai | |
Clutch | Model | Φ430 Diaphragm Spring |
Transmission | Brand and Model | FAST,12JSD160T |
Number of gears | 12 forward gears & 2 reverse | |
Axle | Front Load capacity (kg) | 7500 |
Rear Load capacity (kg) | 18000 | |
Steering | Model | ZF Hydraulic Power Steering |
Steering Wheel | left/right hand drive | LHD |
Frame | Model | 865/317 8+8 |
Electric device | Rated voltage | 24V |
oil tank capacity | 350L | |
Tyres & Quantity | 12.00R20 & 10+1 |
Hubei Runli Special Automobile Co., Ltd is the big domestic enterprise of China, having both the R&D capabilities for special vehicle manufacture and the permission with notice of State Development and Reform Commission.
The main products are
1. Water truck ,Water Tank
2. Fuel tanker truck, Oil Truck,
3. Fire engine truck
4.Truck mounted crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
7. Bulk cement truck
8. Concrete mixer truck
9. Garbage truck,swing arm garbage truck,Self-loading garbage truck,garbage compactor truck,sealed garbage truck
10. Fecal suction truck,sewage suction truck
11. High altitude working truck
12. wrecker truck
13. LED advertisement truck
14. Chemical liquid truck
15. Van truck,insulated truck,refrigeration truck
16. Road sweeper truck,wash and sweep truck
17. High pressure cleaning truck,cleaning and sewage suction truck
18. flatbed transport truck
19. asphalt distributor truck, ynchronous chip sealer truck
20. Dust suppression truck, mist cannon truck
21. Cargo truck, lorry truck
22. Car carrier truck
23. Ambulance,hearse,
24. Tractor Truck
25. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer
Our truck brand :
Dongfeng, sinotruk HOWO, FAW, FOTON, SHACMAN, beiben, CAMC, I S U Z U,GAC H I NO, JAC, JMC, X C M G, IVE CO hongyan , dayun, yuejin, CDW, changan, and so on.
Welcome to visit our company in China !
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Contact name: Ms. Anna Yin
Mobile phone:0086-15072975635
![]() |
